Cable Ladder Making Machine

A Cable Ladder Making Machine, also known as a cable tray system, is an important infrastructure component that provides support and routing for electrical cables and wires. Cable ladders allow organized cable runs and protect cables from environmental factors and mechanical damage.

Cable ladders are extensively used in various industrial settings like power plants, manufacturing facilities, commercial buildings etc. Due to their widespread use, dedicated machines have been developed specifically for efficient and precise manufacturing of cable ladders in different materials, sizes and designs.

This guide provides a comprehensive overview of cable ladder making machines covering their working process, main components, available configurations, applications in the cable management industry, factors to consider when choosing a supplier, price ranges as well as pros, cons and limitations.

Overview of Cable Ladder Making Machines

Cable ladder making machines are heavy-duty equipment designed for high efficiency and precision volume production of cable ladders. They can be categorized into the main types based on working technology:

• •Roll Forming Machines
• •Press Brake Machines
• •CNC Folder Machines

Modern cable ladder manufacturing lines utilize roll forming as the primary metal forming technique due to its continuous, efficient and precision forming capabilities.

The main components of a typical cable ladder making line includes:

• •Roll forming machine
• •Hydraulic shearing machine
• •Supporting uncoiler and coiler units
• •Control console
• •Protective guards and safety devices

These heavy-duty machines require proper installation, operation and preventive maintenance procedures to achieve optimal performance. The production parameters and specifications can also be customized according to application requirements.

Table 1: Main Types of Cable Ladder Making Machines

Working Process of a Roll Forming Cable Ladder Making Line

The typical workflow for the manufacturing of cable ladders using a roll forming system with supporting equipment is as follows:

1. 1.Material Feeding: Coiled metal sheet of the required grade and thickness is loaded on an hydraulic uncoiler.
2. 2.Roll Forming: The sheet gets fed into the forming sections for gradual bending.
3. 3.Incremental Forming: The sequential rolling process shapes the metal into desired cable ladder form.
4. 4.Reshaping: Final touches may be applied using post-forming tools.
5. 5.Cutting: Hydraulic shear machine cuts ladder to the set length.
6. 6.Supporting Operations: Hole punching, deburring, surface treatment etc.
7. 7.Set Collection: Multiple finished ladders collected for batch handling.
8. 8.Exit & Coiling: Formed ladders exiting the line are coiled for logistics.

Table 2: Material, Design and Capabilities

Applications of Cable Ladder Manufacturing Lines

Cable ladder making machines serve metal fabricators providing finished or customizable metal cable trays for various industrial segments:

Industry Sector

• •Power Transmission
• •Power Distribution
• •Telecommunication
• •Construction
• •Infrastructure
• •Commercial Buildings
• •Data Centers
• •Industrial Facilities
• •Railway Networks

Areas of Application

• •Safe overhead cable routing
• •Network cabling infrastructure
• •Cable supports and protection
• •Organized cable runs
• •Easy access for maintenance

Choosing A Reliable Cable Ladder Making Machine Supplier

Choosing an appropriate cable ladder making line supplier is crucial for getting heavy-duty equipment that meets quality and production objectives.

Table 3: Supplier Selection Factors

Reputed manufacturers like Formtek, Jouanel Industries, Anhui HaoSheng Transmission Equipment Co offer customizable cable ladder production lines built with quality components. The approximate price range is $100,000 to $500,000 based on production capacity and configuration complexity.

Pros and Cons of Cable Ladder Making Machines

Table 4: Advantages of Cable Ladder Production Lines

Table 5: Limitations of Cable Ladder Forming Equipment

While automated cable ladder making lines involve major investment and need significant space, their fast and consistent production capabilities make them worthwhile for manufacturers targeting volume production. Periodic maintenance schedules must be followed for optimal functioning. The forming dimensions may also impose limits on the cable tray dimensions.

FAQ

Q: What are the latest technological trends in cable ladder manufacturing equipment?

A: Cable ladder making lines are incorporating more automation, smart sensor-based monitoring and connectivity features under the Industry 4.0 evolution. Forming sections are also getting more versatile to produce perforated, heavier or customized cable tray designs.

Q: Can a single machine provide both roll forming and supporting processes?

A: Integrated cable ladder production lines perform sequential operations like feeding, hole punching, forming, cutting, deburring through inline arrangement of required machinery for an end-to-end automated system.

Q: What factors affect the production rate of cable ladder making equipment?

A: Key factors like sheet thickness, material grade, forming length & complexity, secondary operations determine the output rate which typically ranges from 10 to 50 meters per minute based on specifications.

Q: What kind of regular maintenance is required?

A: Daily cleaning of machine, lubrication of moving parts, inspection of forming rollers & cutting blades as per schedule provided in equipment manual is required. Annual servicing by technicians is also recommended.

Q: Are spare parts and service assistance provided by manufacturers?

A: Reputed cable ladder making machine manufacturers have provisions for customer support by supplying spare parts as needed. Some also provide equipment shifting, installation, operator training services for customer convenience.
